Manufacturing Process& Facilities

Inspection and Testing Equipment

만능재료시험기

Universal testing machine 01

Universal testing machine

A tester that measures the mechanical properties of metallic materials and can perform tensile, compressive, and bending tests. You can also use a Get more precise and accurate measurements with a fixed, 1 μm guaranteed precision extensometer.

Facility details
  • Max load capacity

    50 Kn(5,000 kgf)
  • Load measure precision

    ± 0.2% Within(10% ~ 100%)
  • Load decomposition precision

    Max. ½,000,000(21 bits/Maximum 24 bits available)
  • Minim resolution

    0.003 kgf
  • Movement speed range

    0.01 - 620mm/min Over ※ Accuracy error ±0.03%
만능재료프레스

Tensile specimen press 02

Tensile specimen press

A facility that produces tensile specimens to measure the mechanical properties of metallic materials.

Equipment details
  • Capacities

    5 Ton
  • Maxim pressure

    28 kgf/cm2
  • CYL' stroke

    150mm
  • Motor

    1.5 kw (2 hp)4P
  • Power supply

    220 V3 phase 60 Hz
경도시험기

Micro vickers hardness tester 03

Micro vickers hardness tester

The indenter of a diamond tetragonal weight is pressed against a metal specimen with a constant load, and the slope area of the remaining surface indentation is divided by the test load. divided by the test load.

Equipment details
  • Test Load

    0.01 - 1 Kg
  • Turret Drive

    Automatic (can be manual)
  • Measure range

    Objective 50X (for measurement)-140μm
  • Load Systems

    Electrical Force Load Control
  • Optical System

    Light path separation when using infinity optics, halogen lights, and cameras
금속현미경

Metallurgical microscope 04

Metallurgical microscope

Irradiation is a microscope that shines light on an opaque surface, such as a metal or alloy. and observes the surface according to how much light is reflected.

Equipment details
  • Optical Systems

    CF160/CF60-2
  • Observation Methods

    Thea (MA-P/A, Polarized)
  • Objective Lens

    10x, 20x, 50x, 100
  • Focus

    Coaxial (8.5 mm, 37.7 mm rotation)
  • Interpupillary range

    50mm - 75mm
마운팅프레스

Mounting press 05

Mounting press

A machine that produces (molds) samples for hardness and histological examination of cut sections of metal materials.

Equipment details
  • Pressure gauge

    250 kg/cm2
  • Temperature detectors

    250℃ / Digital thermostats
  • Cooling

    Water Flow System
  • Heater

    1kW
  • Power

    AC 220V, 2pH, 60Hz
폴리싱머신

Polishing machine 06

Polishing machine

A machine that polishes metal surfaces by adhering fine abrasives to them with glue or thermosetting plastic to produce a shiny finish.

Equipment details
  • Table

    1 type (0.45 kW inverter)
  • Wheel Diameter

    0203(8”) Aluminum wheel 1 hole
  • motor

    AC 220V 1/2HP
  • RPM

    0 - 900pm
  • Water supply

    Automatic water flow system
광택측정기

Gloss meter 07

Gloss meter

To measure the gloss of a material surface, direct light from a light source and diffuse reflected light from a material surface. instrument.

Equipment details
  • Projection angle

    20°, 60°, 85°
  • Measurement range

    20° : 0 - 1000 GU
    60° : 0 - 260 GU
    85° : 0 - 160 GU
  • Measurement Diameter

    Ellipse: major axis + minor axis , 61mm * 14
  • Applicable product lines

    Metallic and non-metallic materials, plastics, and more
  • Applicable forms

    flat
